kernels24 (8C+16c)
Threads32 (16+16)
Turbo clock6.00GHz (Thermal Velocity Boost), 5.80GHz (Turbo Boost Max 3.0), 5.60GHz (P-Core), 4.40GHz (E-Core)
Base clock3.20GHz (P-Core), 2.40GHz (E-Core)
TDP125W (Processor Base Power), 253W (Maximum Turbo Power)
graphicno
baseIntel 1700 (LGA1700)
Chipset suitabilityB660, B760, H610, H610E, H670, H770, Q670, Q670E, R680E, Z690, Z790, W680
CodenameRaptor Lake-S
architectureRaptor Cove (P-Core) + Gracemont (E-Core)
productionIntel 7 (10nm)
L2 cache32MiB (8x 2MiB + 4x 4MiB)
L3 cache36MiB
Memory controllerDual Channel DDR4/DDR5, max. 192GB
Memory compatibilitymax. DDR4-3200 (PC4-25600, 51.2GB/s), max. DDR5-5600 (PC5-44800, 89.6GB/s)
Memory compatibility expanded (DIMM)DDR5-5600 (1DPC/1R), DDR5-5600 (1DPC/2R), DDR5-4000 (2DPC/1R), DDR5-3600 (2DPC/2R)
Memory compatibility expanded (SO-DIMM)DDR5-5200 (1DPC/1R), DDR5-5200 (1DPC/2R), DDR5-4400 (2DPC/1R), DDR5-4000 (2DPC/2R)
ECC supportno
SMTyes (P-Core, Intel Hyper-Threading)
Remote maintenanceno
Free multiplierYes
CPU functionsAES-NI, AVX, AVX2, Boot Guard, CET, DL Boost, EIST, GNA 3.0, Idle States, Instruction Set 64bit (Intel 64), Intel Adaptive Boost Technology, ISM, MBEC, OS Guard, Secure Key, Speed Shift, SSE4.1, SSE4.2, Thermal Monitoring, Thread Director, TVB, VMD, VT-d, VT-x, VT-x EPT, XD Bit
System suitability1 socket (1S)
PCIe lanes16x PCIe 5.0, 4x PCIe 4.0
interfaceDMI 4.0, 16GT/s (PCIe 4.0 x8)
Scope of deliverywithout CPU cooler
introduction2023/Q4 (October 16, 2023)
segmentDesktop (Mainstream)
SteppingB0, Spec Code: SRN49
Temperature max.100°C (Tjunction)
- SKU - Κωδικός Εργοστασίου
- BX8071514400
